3" Lift Kit - Fr Spacer - Ford 4WD 08-10
3 Inch Lift Kit | FR Spacer | Ford F-250/F-350 Super Duty 4WD (2008-2010)
Give your 08-10 Ford Super Duty an impressive upgrade, front to back with Rough Country's 3" Ford series suspension lift kit! This easy-to-install lift kit raises the front of your vehicle to be equal height with the rear for a leveled, better-than-stock look that gives an improved ride height and more aggressive appearance.
This kit features a set of front, coil spring spacers allowing you to gain additional ride height without sacrificing ride quality or performance. A set of radius arm drop brackets as well as a track bar drop bracket are provided to keep everything at optimum angles for a factory-like ride, even after lifting.
A set of Rough Country's premium N3 shocks are also included. These fine tuned 10-stage variable high-pressure nitrogen charged shocks offer a fantastic blend of off-road action and smooth highway ride quality. With a durable 18mm spring-loaded piston rod and faster-cooling 54mm shock body. Get the wheels you want!
Rough Country's 3" suspension lift kit comes with everything you need to fit up to a 35" tire with proper wheel backspacing. Best of all, Rough Country's 3" lift kit is backed by our lifetime replacement warranty.
Vehicle fitment & tire options
Vehicle fitment
- 2008-2010 Ford F-350 Super Duty (4WD)
- 2008-2010 Ford F-250 Super Duty (4WD)
Tire / wheel / bolt pattern / offset / notes
35x12.50R20 / Factory 20 / 8x170 / - / -
35x12.50R18 / Factory 18 / 8x170 / - / -
35x12.50R17 / Factory 17 / 8x170 / - / -
35x12.50R17 / 17x9 / 8x170 / -12 / -
33x12.50R17 / 17x9 / 8x170 / -12 / -
315/70R17 / 17x9 / 8x170 / -12 / -
305/70R17 / 17x9 / 8x170 / -12 / -
295/70R17 / 17x9 / 8x170 / -12 / -
285/75R17 / 17x9 / 8x170 / -12 / -
35x12.50R17 / 17x9 / 8x170 / +0 / -
35x12.50R17 / 17x9 / 8x170 / +1 / -
295/70R18 / 18x8.5 / 8x170 / +0 / -
295/70R18 / 18x8.5 / 8x170 / +1 / -
35x12.50R18 / 18x9 / 8x170 / -12 / -
33x12.50R18 / 18x9 / 8x170 / -12 / -
295/70R18 / 18x9 / 8x170 / -12 / -
285/75R18 / 18x9 / 8x170 / -12 / -
35x12.50R18 / 18x9 / 8x170 / +0 / -
33x12.50R18 / 18x9 / 8x170 / +0 / -
295/70R18 / 18x9 / 8x170 / +0 / -
285/75R18 / 18x9 / 8x170 / +0 / -
35x12.50R18 / 18x9 / 8x170 / +1 / -
33x12.50R18 / 18x9 / 8x170 / +1 / -
295/70R18 / 18x9 / 8x170 / +1 / -
285/75R18 / 18x9 / 8x170 / +1 / -
295/70R18 / 18x10 / 8x170 / -25 / -
295/70R18 / 18x10 / 8x170 / -19 / -
295/70R18 / 18x10 / 8x170 / -18 / -
35x12.50R20 / 20x9 / 8x170 / -12 / -
35x11.50R20 / 20x9 / 8x170 / -12 / -
33x12.50R20 / 20x9 / 8x170 / -12 / -
305/55R20 / 20x9 / 8x170 / -12 / -
295/65R20 / 20x9 / 8x170 / -12 / -
295/60R20 / 20x9 / 8x170 / -12 / -
35x12.50R20 / 20x9 / 8x170 / +0 / -
35x12.50R20 / 20x9 / 8x170 / +1 / -
35x12.50R20 / 20x10 / 8x170 / -25 / Minor Trimming
35x12.50R20 / 20x10 / 8x170 / -19 / Minor Trimming
33x12.50R20 / 20x10 / 8x170 / -19 / Minor Trimming
305/55R20 / 20x10 / 8x170 / -19 / Minor Trimming
295/60R20 / 20x10 / 8x170 / -19 / Minor Trimming
35x12.50R20 / 20x10 / 8x170 / -18 / Minor Trimming
33x12.50R20 / 20x10 / 8x170 / -18 / Minor Trimming
305/55R20 / 20x10 / 8x170 / -18 / Minor Trimming
295/60R20 / 20x10 / 8x170 / -18 / Minor Trimming
35x12.50R20 / 20x12 / 8x170 / -44 / Trimming Required
33x12.50R20 / 20x12 / 8x170 / -44 / Trimming Required
305/55R20 / 20x12 / 8x170 / -44 / Trimming Required
35x12.50R22 / 22x10 / 8x170 / -25 / Minor Trimming
35x12.50R22 / 22x10 / 8x170 / -19 / Minor Trimming
33x12.50R22 / 22x10 / 8x170 / -19 / Minor Trimming
285/55R22 / 22x10 / 8x170 / -19 / -
35x12.50R22 / 22x10 / 8x170 / -18 / Minor Trimming
33x12.50R22 / 22x10 / 8x170 / -18 / Minor Trimming
285/55R22 / 22x10 / 8x170 / -18 / -
35x12.50R22 / 22x12 / 8x170 / -44 / Trimming Required
33x12.50R22 / 22x12 / 8x170 / -44 / Trimming RequiredFeatures
- Easy bolt-on installation
- Maintains factory ride quality
- Increased ground clearance
- Levels the front with the rear of the vehicle
- Radius arm drop brackets allow for properly set caster. Proper caster is crucial to maintaining factory handling and drivability.
Product specifications
Product category: Susp Lift Kits 4wd
Manufacturer: Rough Country
Manufacturer part number: 516.20
UPC: 843030127527
Country of origin: United States
Manufacturer-listed weight: 97.40 lbs
Product notes & installation
Included components
Front components
- Coil spring spacers
- Radius arm drop brackets
- Track bar drop bracket
- Hardware
Rear components
- 2in lift blocks
- U-bolts
- Hardware
